Ruijie RG-ES100 Series Switches Hardware Installation and Reference Guide Appendix B Mini-GBIC and SPF+ Module
Mini-GBIC-LX-SM1310
LC
SMF
9/125
10km
GE-eSFP-SX-MM850
LC
MMF
62.5/125
275m
50/125
550m
GE-eSFP-LX-SM1310
LC
SMF
9/125
10km
GE-SFP-LX-SM1310
LC
SMF
9/125
10km
Mini-GBIC-LH40-SM1310
LC
SMF
9/125
40km
GE-SFP-SX-SM1310-BIDI
LC
MMF
50/125
500m
GE-SFP-SX-SM1550-BIDI
LC
MMF
50/125
500m
GE-SFP-LX20-SM1310-BIDI
LC
SMF
9/125
20km
GE-SFP-LX20-SM1550-BIDI
LC
SMF
9/125
20km
GE-SFP-LH40-SM1310-BIDI
LC
SMF
9/125
40km
GE-SFP-LH40-SM1550-BIDI
LC
SMF
9/125
40km
MINI-GBIC-ZX50-SM1550
LC
SMF
9/125
50km
MINI-GBIC-ZX80-SM1550
LC
SMF
9/125
80km
MINI-GBIC-ZX100-SM1550
LC
SMF
9/125
100km
GE-SFP-SX
LC
MMF
62.5/125
275m
50/125
550m
GE-SFP-LX
LC
SMF
9/125
10km
Mini-GBIC-GT
RJ45
Category 5 (or above ) UTP or STP
100m
For the optical module with transmission distance exceeding 40 km and more, one on-line optical attenuator should
be added on the link to avoid the overload of the optical receiver when short single-mode optical fibers are used.
Optical modules generate laser. Do not stare at light source.
To keep optical modules clean, please use dust caps when the modules are not connected with fibers.
No extra cables are needed when SFP cables are used. Inserting the two ends of a SFP cable into corresponding
ports facilitates inter-communication between the two ports.
Table B-8 Specifications of SFP BIDI Optical Module Pairs
Rate/Distance
Module Pairs
1000M/500m
GE-SFP-SX-SM1310-BIDI
GE-SFP-SX-SM1550-BIDI
1000M/20km
GE-SFP-LX20-SM1310-BIDI
GE-SFP-LX20-SM1550-BIDI
1000M/40km
GE-SFP-LH40-SM1310-BIDI
GE-SFP-LH40-SM1550-BIDI
The BIDI modules must be used in pairs (e.g., GE-SFP-LX20-SM1310-BIDI and GE-SFP-LX20-SM1550-BIDI).
