Ruijie RG-ES100 Series Switches Hardware Installation and Reference Guide Product Installation
The wall mounting procedure for the RG-ES126G-LP-L switch is the same as that of the RG-ES126G-P-L.
SUITABLE FOR MOUNTING ON CONCRETE OR OTHER NON-COMBUSTIBLE SURFACE ONLY.
3.3.3 Mounting the Switch on a Table
Attach the four rubber pads to the recessed areas on the bottom of the switch, as shown in Figure 3-7.
Figure 3-7 Attaching the Rubber Feet to the Recessed Areas
Figure 3-8 Attaching the Rubber Pads to the Recessed Areas
