Ruijie RG-ES100 Series Switches Hardware Installation and Reference Guide Product Overview
1 Product Overview
The RG-ES100 series switches include the following models:
Table 1-1 RG-ES100 Series Switches
Model
10/100/1000 Base-T
Auto-sensing Ethernet Port
1000Base-X SFP Port
Console Port
RG-ES109G-LP-L
9 (Ports 1-8 support
PoE+/PoE）
N/A
N/A
RG-ES126G-P-L
24 (1-24 ports support
PoE+/PoE）
2
N/A
RG-ES126G-LP-L
24 (1-24 ports support
PoE+/PoE）
2
N/A
The SPF ports cannot be downward compatible with 100Base-FX.
1000Base-T is compatible with 100Base-TX and 10Base-T in the downlink direction.
1.1 RG-ES109G-LP-L
Technical Specifications
Model
RG-ES109G-LP-L
Power Supply
 AC input
Rated voltage range: 100V to 240V
Maximum voltage range: 90V to 264V
Frequency: 50/60 Hz
Rated current: 1.5A
Power cord requirement: 10A
 Adapter output
Rated voltage range: 54V DC
Rated current range: 1.11A
EEE
Not supported
PoE
Supports PoE and PoE+.
Ports 1-8 are PoE/PoE+-capable with the maximum power output of 30W per port. Port 9 does
not support PoE or PoE+.
The overall maximum output power of PoE/PoE+ is 54W.
PoE Mode
Mode A (data pairs 1-2 and 3-6)
Power
Consumption
Less than 7W with no PoE load
Less than 64W with PoE full load
Port Mode LED
When the button is turned to the left position (Mode 1), the LED indicates the switching status
