Hardware Installation and Reference Guide Product Overview
13
Front Panel
Figure 1-14 Front Panel of RG-S2915-10GT2MS-L Switch
Description:
1. System status LED
2. USB port
3. Console port
4. 10/100/1000Base-T adaptive Ethernet port
5. SFP port status LED
6. SFP port
Back Panel
Figure 1-15 Back Panel of RG-S2915-10GT2MS-L Switch
