Hardware Installation and Reference Guide Product Overview
4
Power Supply
The RG-S2915-24GT4MS-L switch adopts an AC power supply.
AC input:
Rated voltage range: 100 V AC to 240 V AC; 50 Hz/60 Hz
Maximum voltage range: 90 V AC to 264 V AC; 47 Hz to 63 Hz
Frequency: 50 Hz/60 Hz
Rated current: 0.6 A
Power cord requirements: 10 A power cord
Heat Dissipation
The RG-S2915-24GT4MS-L switch adopts natural heat dissipation without fans. To ensure proper heat dissipation, maintain a
minimum clearance of 10 cm (3.94 in.) on both sides and around the back panel of the chassis for air circulation. Besides, dust the
device every three months to avoid blocking the ventilation openings on the housing.
Figure 1-4 Airflow Direction of RG-S2915-24GT4MS-L Switch
The switch should be installed at least 1 U (44.45 mm/1.75 in.) away from the neighbor device for normal heat dissipation.
LED
The system is being initialized.
The system is operating normally.
A system over-temperature alarm occurs.
1. The temperature severely exceeds the
threshold, and the system will be reset and
restart.
2. A system failure occurs.
10/100/1000 Mbps
copper port status
No link is detected for this port.
The port has a 10/100/1000 Mbps link up.
