Front Panel
Figure 1-2 Front Panel of RG-S2915-24GT4MS-L Switch
Description:
1. System status LED
2. USB port
3. Console port
4. 10/100/1000Base-T adaptive Ethernet port
5. SFP port status LED
6. SFP port
Back Panel
Figure 1-3 Back Panel of RG-S2915-24GT4MS-L Switch
Description:
1. Grounding stud
2. Power cord retention clip hole
3. Power plug
