Ruijie RG-S2915-L Series User Manual

Hardware Installation and Reference Guide Product Overview
14
Description:
1. Grounding stud
2. Power cord retention clip hole
3. Power plug
Power Supply
The RG-S2915-10GT2MS-L switch adopts an AC power supply.
 AC input:
Rated voltage range: 100 V AC to 240 V AC; 50 Hz/60 Hz
Maximum voltage range: 90 V AC to 264 V AC; 47 Hz to 63 Hz
Frequency: 50 Hz/60 H
Rated current: 0.6 A
Power cord requirements: 10 A power cord
Heat Dissipation
The RG-S2915-10GT2MS-L switch adopts natural heat dissipation without fans. To ensure proper heat dissipation, maintain a
minimum clearance of 10 cm (3.94 in.) on both sides and around the back panel of the chassis for air circulation. Besides, dust the
device every three months to avoid blocking the ventilation openings on the housing.
Figure 1-16 Airflow Direction of RG-S2915-10GT2MS-L Switch
