Hardware Installation and Reference Guide Product Overview
18
2. Power cord retention clip hole
Power Supply
The RG-S2915-10GT2MS-P-L switch adopts an AC power supply.
AC input:
Rated voltage range: 100 V AC to 240 V AC; 50 Hz/60 Hz
Maximum voltage range: 90 V AC to 264 V AC; 47 Hz to 63 Hz
Frequency: 50 Hz/60 Hz
Rated current: 3 A
Power cord requirements: 10 A power cord
Heat Dissipation
The RG-S2915-10GT2MS-P-L switch adopts the ventilation mode of air inlet from the left and right sides and air outlet through the
rear side to ensure that the device works properly under specified environment. When placing a chassis, maintain a minimum
clearance of 10 cm (3.94 in.) on both sides and around the back panel of the chassis for air circulation. Dust the device every three
months to avoid blocking the ventilation openings on the housing.
Figure 1-20 Airflow Direction of RG-S2915-10GT2MS-P-L Switch
