Ruijie RG-S6150-X Series User Manual

Hardware Installation and Reference Guide Appendix
49
GE-SFP-LX20-
SM1310-BIDI
LC
SMF
9/125
20 km
GE-SFP-LX20-
SM1550-BIDI
LC
SMF
9/125
20 km
GE-SFP-LH40-
SM1310-BIDI
LC
SMF
9/125
40 km
GE-SFP-LH40-
SM1550-BIDI
LC
SMF
9/125
40 km
SFP-S4-R1000P1
V1
1310
SMF
9/125
10 km
Table 7-5 Pairing Models of BIDI SFP Modules
Rate/Distance
Paring Models
1000 Mbps/20 km
GE-SFP-LX20-SM1310-BIDI
GE-SFP-LX20-SM1550-BIDI
1000 Mbps/40 km
GE-SFP-LH40-SM1310-BIDI
GE-SFP-LH40-SM1550-BIDI
Note
BIDI SFP modules must be used in pairs. If GE-SFP-LX20-SM1310-BIDI is used at one end, then GE-SFP-
LX20-SM1550-BIDI must be applied to the other end.
Table 7-6 Models and Technical Specifications of 10G SFP+ Modules
Model
Wavelength
(nm)
Optical
Fiber
Type
Core
Size
(μm)
Modular
Bandwidt
h
(MHz·km)
Max
Cabling
distance
Intensity of
Transmitted
Light (dbm)
Intensity of
Received
Light (dbm)
min
max
min
max
XG-
SFP-
SR-
MM85
0
850
MMF
(LC
connector)
62.5
200
33 m
-7.3
-1
-9.9
-1
160
26 m
50
2000
300 m
500
82 m
400
66 m
XG-
SFP-
LR-
SM131
0
1310
SMF
(LC
connector)
9
N/A
10 km
-8.2
0.5
-14.4
0.5
