F11GIM User Manual
3.5 Propellers
Copyright ©2021 Ruko All Rights Reserved.14
Installation location
Installed to the motor with A
mark on the arm
Installed to the motor with B
mark on the arm
Mark A Propellers Mark B
Attaching the Propellers
Taking the camera direction as the front, the left front arm and right rear arm must be
equipped with propellers marked with A; the right front arm and left rear arm must be
equipped with propellers marked with B. Use a screwdriver to install and make sure the
screws are tightened.
Detaching the Propellers
Use the screwdriver to detach the propellers from the motors.
Please use the propellers provided by Ruko, and do not mix propellers of different types.
Please check whether the propeller is installed correctly and tightly before each flight.
Before each flight, please check to make sure that the propellers are in good condition.
Make sure that the ESC emits a tone after the Aircraft is powered on.
The propellers on the adjacent motors of the F11 GIM are forward and reverse propellers. The
two propellers on the same motor are the same, and the propellers are marked with A and B
respectively. The rotation directions of the propellers with the same mark are different.
B
B
A
A
A
A
B
B
