RUKO F11 GIM - Preparing the Aircraft

F11GIM User Manual
Unfold the front arms
Take off the Gimbal Cover
Unfold the rear arms and then unfold all the propellers
Gimbal
Propeller
Motor
Copyright ©2021 Ruko All Rights Reserved. 5
Unfold the front arms before unfolding the rear arms.
Before powering on the aircraft, ensure that the front and rear arms are extended and
the camera is placed on the horizontal ground. Ensure that there is sufficient space
under the camera to prevent the camera angle from being stuck to the ground during
the self-check.
All aircraft arms are folded before the aircraft is packaged. Follow the steps below
to unfold the aircraft arms.
2.4 Aircraft Diagram
2.3 Preparing the Aircraft
①
②
③
LED indicator Light
Intelligent battery
Power button
④
⑤
⑥
