SPECIFICATION（EWX5000）
Rated line pull
5000 lbs (2268 kgs)
Motor: permanent magnet
12V:Input: 3.4 kW / 4.5hp; Output: 1. 4 kW / 1.9hp
24V:Input: 3.4 kW / 4.5hp; Output: 1.7 kW / 2.3hp
Gear reduction ratio 280:1
Cable (Dia.× L) Ø1/4 "×79 ' (Ø6.4mm×24m)
Drum size (Dia.× L) Ø2.48 "×5.3 " (Ø63mm×133.5 mm)
Mounting bolt pattern 6.55 "×4.5 " (166.4mm×114.3 mm) 4-M10
Item EWX5000U EWX5000S
Overall dimensions
(L×W×H)
18.0"×6.3 "×10.0 "
456mm ×160mm ×254mm
17.3 "×6.3 "×11.1 "
440mm ×160mm ×283mm
Net weight
Ibs(kgs)
54.5
24.7
55.6
25.2
Pull, Speed, Amperes, Volts (First layer):
Line Pull Line Speed ft/min (m/min) Current A
Ibs (kgs) 12V DC 24V DC 12V DC 24V DC
0 12.8 (3.9) 12.5 (3.8) 45 25
1000(454) 11.5 (3.5) 10.8 (3.3) 90 40
3000(1361) 9.2 (2.8) 8.9 (2.7) 170 80
5000(2268) 7.2 (2.2) 7.9 (2.4) 280 140
Line Pull And Rope Capacity In Layer
Layer Rated line pull lbs (kgs) Total rope on the drum ft (m)
1 5000(2268) 16.4(5.0)
2 4259(1932) 35.8(10.9)
3 3710(1683) 57.1(17.4)
4 3286(1490) 78.9(24.0)
