SPECIFICATION（EWX6000）
Rated line pull
6000 lbs (2722kgs)
Motor: permanent magnet
12V:Input: 2.8 kW / 3.7hp; Output: 1. 6 kW / 2.1hp
24V:Input: 2.9kW / 3.9hp; Output: 1.7 kW / 2.3hp
Gear reduction ratio 280:1
Cable (Dia.× L) Ø9/32 "×105 ' (Ø7.2mm×32m)
Drum size (Dia.× L) Ø2.48 "×8.8 " (Ø63mm×223 mm)
Mounting bolt pattern 10 "×4.5 " (254mm×114.3 mm) 4-M10
Item EWX6000U EWX6000S
Overall dimensions
(L×W×H)
21.4"×6.3 "×10.0 "
544mm ×160mm ×254mm
20.8"×6.3 "×11.1 "
527mm ×160mm ×283mm
Net weight
Ibs(kgs)
66.1
30.0
67.2
30.5
Pull, Speed, Amperes, Volts (First layer):
Line Pull Line Speed ft/min (m/min) Current A
Ibs (kgs) 12V DC 24V DC 12V DC 24V DC
0 12.8（3.9） 14.1 (4.3) 45 30
2000(907) 8.2 (2.5) 8.8 (2.7) 100 45
4000(1814) 7.2 (2.2) 7.9 (2.4) 150 80
6000(2722) 5.9 (1.8) 6.9 (2.1) 230 120
Line Pull And Rope Capacity In Layer
Layer Rated line pull lbs (kgs) Total rope on the drum ft (m)
1 6000(2722) 22.0(6.7)
2 4979(2258) 47.9(14.6)
3 4255(1930) 77.1(23.5)
4 3714(1685) 105.0(32.0)
