SPECIFICATION（EWX9500）
Pull, Speed, Amperes, Volts (First layer):
Line Pull Line Speed ft/min (m/min) Current A
Ibs (kgs) 12V DC 24V DC 12V DC 24V DC
0 19.7 (6.0) 22.3 (6.8) 80 70
3000(1361) 12.5 (3.8) 16.4(5.0) 170 140
6000(2722)
9.8（3.0）
12.8 (3.9) 260 210
9500(4309) 6.2（1.9） 9.5(2.9) 380 270
Line Pull And Rope Capacity In Layer
Layer Rated line pull lbs (kgs) Total rope on the drum ft (m)
1 9500(4309) 17.4(5.3)
2 7706(3495) 39.4(12.0)
3 6482(2940) 65.0(19.8)
4
5593(2537)
85.3(26.0)
Rated line pull
9500 lbs (4309 kgs)
Motor: series wound
12V:Input: 4.6kW / 6.1hp; Output: 2.1kW / 2.8hp
24V:Input: 6.5kW / 8.7hp; Output: 2.8kW / 3.8hp
Gear reduction ratio 230:1
Cable (Dia.× L) Ø3/8"×85 ' (Ø9.2mm×26m)
Drum size (Dia.× L) Ø2.48 "×8.8 " (Ø63mm×223 mm)
Mounting bolt pattern 10 "×4.5 " (254mm×114.3 mm) 4-M10
Item EWX9500U EWX9500S EWX9500F
Overall dimensions
(L×W×H)
21.3"×6.3"×10.0"
540 mm ×160mm ×254mm
21.3"×6.3"×11.1"
540mm ×160 mm ×283 mm
21.3"×6.5"×9.9"
540mm ×166mm ×251mm
Net weight
Ibs(kgs)
80.7
36.6
81.7
37.1
86.5
39.2
