SPECIFICATION（EWX8000）
Rated line pull 8000 lbs (3629kgs)
Motor: series wound
12V:Input: 4.3kW / 5.8hp; Output: 2.0kW / 2.7hp
24V:Input: 5.5kW / 7.4hp; Output: 2.8kW / 3.8hp
Gear reduction ratio 230:1
Cable (Dia.× L) Ø21/64"×95 ' (Ø8.3mm×29m)
Drum size (Dia.× L) Ø2.48 "×8.8 " (Ø63mm×223mm)
Mounting bolt pattern 10 "×4.5 " (254mm×114.3 mm) 4-M10
Item EWX8000U EWX8000S EWX8000F
Overall dimensions
(L×W×H)
21.3"×6.3"×10.0"
540 mm ×160mm ×254mm
21.3"×6.3"×11.1"
540mm ×160 mm ×283mm
21.3"×6.5"×9.9"
540mm ×166mm ×251mm
Net weight
Ibs(kgs)
71.9
32.6
77.3
35.1
82.1
37.2
Pull, Speed, Amperes, Volts (First layer):
Line Pull Line Speed ft/min (m/min) Current A
Ibs (kgs) 12V DC 24V DC 12V DC 24V DC
0 17.7(5.4) 25.6(7.8) 80 70
3000(1361) 11.5(3.5) 15.4(4.7) 190 140
5000(2268) 9.2(2.8) 12.1(3.7) 260 190
8000(3629) 5.9(1.8) 8.5(2.6) 360 230
Line Pull And Rope Capacity In Layer
Layer Rated line pull lbs (kgs) Total rope on the drum ft (m)
1 8000(3629) 20.0 (6.1)
2 6529(2962) 44.3 (13.5)
3 5515(2502) 72.2 (22.0)
4 4773(2165) 95.1 (29.0)
