SPECIFICATION（EWX9500SG2）
Rated line pull 9500 lbs (4309 kgs)
Motor: series wound
12V:Input: 4.6kW / 6.1hp; Output: 2.1kW / 2.8hp
24V:Input: 6.5kW / 8.1hp; Output: 2.8 kW / 3.8hp
Gear reduction ratio 230:1
Cable (Dia.× L) Ø3/8"×45.9 ' (Ø9.2mm×14.0m)
Drum size (Dia.× L) Ø2.48 "×4.7 " (Ø63mm×120mm)
Mounting bolt pattern
5.9 "×4.5 " (151mm×114.3 mm) 4-M10
Overall dimensions
(L×W×H)
17.2"×6.3"×11.1"
437mm ×160 mm ×283 mm
Net weight
Ibs(kgs)
65.0
29.5
Pull, Speed, Amperes, Volts (First layer):
Line Pull Line Speed ft/min (m/min) Current A
Ibs (kgs) 12V DC 24V DC 12V DC 24V DC
0 19.7 (6.0) 22.3 (6.8) 80 70
3000(1361) 12.5 (3.8) 16.4(5.0) 170 140
6000(2722)
9.8（3.0）
12.8 (3.9) 260 210
9500(4309) 6.2（1.9） 9.5(2.9) 380 270
Line Pull And Rope Capacity In Layer
Layer Rated line pull lbs (kgs) Total rope on the drum ft (m)
1 9500(4309) 9.8(3.0)
2 7706(3495) 24.6 (7.5)
3 6482(2940) 42.7(13.0)
4 5593(2537) 45.9 (14.0)
