MODEL 53515/53615/63515/63615/73515/73615
18
Slow Rinse
Time
45：00
0～99：59
Slow rinse time (Minute : Second)
Fast Rinse
Time
10：00
0～99：59
Fast rinse time (Minute : Second)
Brine Refill
Time
05：00
0～99：59
Brine refill time (Minute : Second)
Maximum
Interval
Regenerati
on Days
H-30
30
0～40
Regenerate on the day even though the
available volume of treated water does
not drop to zero (0).
Output
Control
Mode
b-01
01
01 or 02
Mode b-01: signal will turn on during the
regeneration (refer to P3)
Mode b-02: Signal is only available at
intervals of regeneration cycles and in
service. (refer to the P3)
B. Process Display (Take 63615 A-01 as an example)
Figure A Figure B Figure C
Figure D Figure E Figure F
Figure G Figure H Figure J
Illustration:
 In Service status, the figure shows Figure A/B/C/D; In Backwash status,
it shows Figure E/C; In Brine Draw status, it shows Figure F/C; In Slow
Rinse status, it shows Figure G/C; In Fast Rinse status, it shows Figure
