Runxin 55504 User Manual

MODEL：F67Q/F71Q/F68Q/F69Q/F116Q/F117Q
61
F68Q3 Valve Body Components and No.
［F68Q1 doesn't have No.16, 30 and
31, and change No. 9 from 8865174 (630) to 8865175 (631)］
Ite
m
No.
Description Part No.
Qu
anti
ty
Ite
m
No.
Description Part No.
Qu
anti
ty
1 O-ring 73×5.3 8378143 1 27 Moving Disk 8459078 1
2 O-ring 25.8×2.65 8378078 1 28 Fixed Disk 8469079 1
3
Valve Body
(ABS+GF10)
5022022
1 29 Seal Ring 8370111 1
Valve Body
(PPO+GF20)
5022023
4 Motor 6158011 1 30
Animated
Connector
5457002 1
5
Screw, Cross
ST3.9×16
8909016 4 31 Flow Meter 5447018 1
6 Small Gear 8241003 1 32 Seal Ring 8371001 2
7 Pin 8993003 1 33 Plug 8323002 1
8 Wire for Power 5513001 1 34 Seal Ring 8370003 1
9 Label
8865175
(631)
1 35 BLFC 8468055 1
10 Front Cover 8300060 1 36 O-ring 11×2 8378169 1
11
Wire for Locating
Board
5511021 1 37 Connector 8458068 1
12 Cable Clip 8126004 2 38 Tube 8457004 1
13 Control Board 6382159 1 39 Hex Nut 8940001 1
14
Screw, Cross
ST2.2×6.5
8909004 2 40 Animated Nut 8945025 1
15 Dust Cover 8005091 1 41 Connector 8458064 1
16 Probe Wire 6386014 1 42 O-ring 15×1.8 8378179 1
17
Screw, Cross
ST3.9×13
8909013 1 43 DLFC
Without this
part
1
18
Gear
8241053
1
44
Clip
8270010
1
19
Screw, Cross
ST2.9×16
8909008 2 45
Screw, Cross
M5×35
8902017 2
20
Locating Board
6380032
1
46
Cover of Injector
8315001
1
21
Fitting Nut
8092004
1
47
O-ring 30×1.8
8378025
1
22
O-ring 73×3.55
8378128
2
48
Nozzle, Injector
8454008
1
23
O-ring 38.7×3.55
8378184
2
49
Throat, Injector
8467008
1
24
Anti-friction Washer
8216004
1
50
Injector Body
8008010
1
25 Shaft 8258004 1 51
O-ring
10.82×1.78
8378012 1
