Runxin 63510 User Manual

MODEL: N74A1-63510/N74A3-63610/N74B1-63510B/N74B3-63610B
7
B. Technical Parameters
Model
Transformer
Output
Flow Rate
m
3
/h
@0.3 MPa
Regeneration
Type
Installation
Type
N74A1（63510）
DC24V, 1.5A
10
Time clock
type by days
Top-mounted
N74A3（63610）
Meter type
N74B1
（63510B）
DC24V, 1.5A
10
Time clock
type by days
Top-mounted
or
side-mounted
N74B3
（63610B）
Meter type
1.5. Installation
A. Installation notice
Before installation, read all those instructions completely. Then obtain
all materials and tools needed for installation.
The installation of product, pipes and circuits, should be accomplished
by professional to ensure the product can operate normally.
Perform installation according to the relative pipeline regulations and
the specification of Water Inlet, Water Outlet, Drain Outlet, Brine Line
Connector.
B. Device location
① The softener should be located close to drain.
② Ensure the unit is installed in enough space for operating and
maintenance.
③ Brine tank need to be close to softener.
④ The unit should be kept away the heater, and not be exposed outdoor.
Sunshine or rain will cause the system damage.
⑤ Please avoid to install the system in one Acid/Alkaline, Magnetic or
strong virbration circumstance, because above factors will cause the
system disorder.
⑥ Do not install the filter or softener, drain pipeline in circumstance which
