Runxin F63C3 User Manual

MODEL 63504-F63C1/63604-F63C3/73504-F68C1/73604-F68C3
52
F63C3 /F63C1 Valve Body Components (Item No. 20, 35, 36 only for F63C3)
Item
No.
Description
Part No.
Quan
tity
Item
No.
Description
Part No.
Quantit
y
1
O-ring 73×5.3
8378143
1
27
O-ring 73X3.55
8378128
2
2
O-ring25.8×2.65
8378078
1
28
O-ring 37.7X3.55
8378118
2
3
Valve Body
5022033
1
29
Anti-friction
Washer
8216004
1
5022034
30
Shaft
8258004
1
4
Screw, Cross
ST3.9X16
8902016
4
31
Moving Seal
Ring
8370001
1
5
Screw, Cross
M4X30
8909009
4
32
Moving Disk
8459001
1
6
Motor
6158011
1
33
Fixed Disk
8469001
1
7
Small Gear,
Motor
8241003
1
34
Seal Ring
8370002
1
8
Pin
8993001
1
35
Animated
Connector
5457002
1
9
Wire for power
5513001
1
36
Flow Meter
5447001
1
10
Label
8865002
1
37
Seal Ring
8371002
1
11
Front Cover
8300001
1
38
Plug
8323002
1
12
Seal Ring
8370003
1
39
Seal Ring
8370003
1
13
Display Board
8381003
1
40
Brine Line Flow
Control
8468002
1
14
Wire for Display
Board
5512001
1
41
Tube
8457004
1
15
Cable Clip
8126004
2
42
Hexagonal Nut
8940001
1
16
Wire for Locating
Board
5511001
1
43
Joint
8458017
1
17
Control Board
8328003
1
44
Drain Line Flow
Control
8468007
1
18
Screw, Cross
8909004
4
45
Screw, Cross
M5X35
8902017
2
19
Dust Cover
8005006
1
46
Cover, Injector
8315001
1
20
Probe wire
6386001
1
47
O-ring 30X1.8
8378025
1
21
Screw, Cross
ST2.9X16
8909010
3
48
Nozzle, Injector
8454009
1
22
Screw, Cross
ST3.9X13
8909013
1
49
Throat, Injector
8467009
1
23
Big Gear, Driven
5241002
1
50
Injector Body
8008001
1
24
Screw, Cross
ST2.9X9.5
8909008
7
51
O-ring
10.82X1.78
8378012
1
25
Locating Board
8380001
1
52
O-ring 7.5X1.8
8378016
2
26
Fitting Nut
8092004
1
