28 RUSH MH 1 Profile Plus User Manual
DMX protocol
Chan. Value Function
1 0-255 Pan 0°-540°
2 0-255 Pan (fine control)
3 0-255 Tilt 0°-270°
4 0-255 Tilt (fine control)
5 0-254 Pan/tilt speed, fast- slow
255 Pan/tilt speed, fast
6 0-255 Dimmer 0-100%
7 Strobe
0-7 Off
8-15 Open
16-131 Strobe, slow-fast
132-139 Open
140-181 Fast close, slow open
182-189 Open
190-231 Slow close, fast open
232-239 Open
240-247 Random strobe
248-255 Open
8 Color wheel 1
0-7 Color 1 – Open
8-15 Color 2 – Light Blue
16-23 Color 3 – Green
24-31 Color 4 – Orange
32-39 Color 5 – Yellow
40-47 Color 6 – Magenta
48-55 Color 7 – Dark blue
56-63 Color 8 – Red
64-127 Indexing
128-189 Clockwise, fast-slow
190-193 Stop
194-255 Counter-clockwise, slow-fast
9 Color wheel 2
0-7 Color 1 – Open
8-15 Color 2 – Pink
16-23 Color 3 – CTO 3200 K
24-31 Color 4 – Purple
32-39 Color 5 – Yellow
40-47 Color 6 – Green
