36 RUSH Wizard User Manual
DMX protocol
Chan. Value Function
Fade
type
Default
value
1
Shutter
Snap 10
0-7 Close
8-15 Open
16-131 Strobe, slowfast
132-167 Pulse effect, fast close, slow open
168-203 Pulse effect, slow close, fast open
204-239 Pulse open & close
240-247 Random strobe, slowfast
248-255 Open
2
Dimmer
Fade 0
0-255 Closed 0% open 100%
3
Color wheel: continuous scrolling
Snap 0
0 Open
1-14 Open Blue
15 Blue
16-29 Blue Magenta
30 Magenta
31-44 Magenta Yellow
45 Yellow
46-59 Yellow Dark Blue
60 Dark Blue
61-74 Dark Blue White
75 White
76-89 White Red
90 Red
91-104 Red Orange
105 Orange
106-119 Orange Green
120-158 Green
Color wheel: stepped scrolling
159 -160 Open
161-163 Blue
164-166 Magenta
167-169 Yellow
170-172 Dark Blue
173-175 White
