BA.GB.12-27409-05-07-FTA-jr
6.5.2.3 Switching the searchlight on or off resp. (optional extra)
Pre-condition:
Switch on control stand „Cage control“ or „Emergency Control“.
Execution at operating panel
actuate push button „Searchlight“
or
actuate push button „Searchlight“
6.5.2.4 Operation of the joystick
1. Unlock joystick by pulling the notch (1).
2. Move joystick into the direction of the in-
scription of the desired movement. The
speed of the movements is controlled
over the angle of deflection ().
3. For stopping the movement put back the
joystick in the neutral position.
Attention!
In order to avoid swinging motions, a sudden deflection
and release of the joystick must be avoided.
You can set the control in such a way that either four or two boom move-
ments can be carried out simultaneously. The following points must be ob-
served during operating the joystick:
„3 movements at the same“
