4 Operating elements and
displays
4-4
RUTHMANN-Steiger
®
TB270
BA.GB.12-27409-05-07-FTA-jr
jacks shine at the same time, when
the control system detects a differ-
ent correct jacking-variant.
Check inclination by means of level-
ling indicator!
1.
Luminous push but-
ton „Left within pro-
file“ / „Jack front
right“
 Push function:
- Jacking variant with stabilizing jacks
extended horizontically on the right
side, on the left side within the vehi-
cle profile.
- Jacking on both sides within vehicle
profile after having reached the min-
imum jacking.
- Activates push button „Jack vertical
down“ for control of front right jack.
 Blinking light:
- Jack has ground contact.
 Permanent light:
- See luminous push button „Full
jacking / Jack rear right“.
1.
Luminous push but-
ton „Right within pro-
file“ / „Jack front left“
 Push function:
- Jacking variant with stabilizing jacks
extended horizontically on the left
side, on the right side within the ve-
hicle profile.
- Jacking on both sides within vehicle
profile after having reached the min-
imum jacking.
- Activates push button „Jack vertical
down“ for control of front left jack.
 Blinking light:
- Jack has ground contact.
 Permanent light:
- See luminous push button „Full
jacking / Jack rear right“.
1.
Luminous push but-
ton „Minimum jack-
ing“ / „Jack rear left“
 Push function:
- Minimum jacking.
- Activates push button „Jack vertical
down“ for control of rear left jack.
 Blinking light:
- Jack has ground contact.
 Permanent light:
- See luminous push button „Jack
rear right“.
1.
Push button
 Push function, only vertical extension
