„Jack vertical down“
of the stabilizing jack. Only in con-
nection with push button „Jack rear
left“, „Jack front left“, „Jack front
right“ and / or „Jack rear right“.
1.
Push button
„Jacks up“
 Push function, all stabilizing jacks
drive in first vertically, then horizonti-
cally.
1.
Luminous push but-
ton „Basic Position“
 Push function, move Steiger into the
basic position automatically.
 Permanent light:
- Steiger not in basic position.
1.
Push button
„Special Function“
 Switching the fine control on or off.
1.
Push button
„Stop“
 Push function, stops vehicle engine.
1.
Push button
„Start“
 Push function, starts vehicle engine.
1.
Push button
„Cage Rotation left“
 Push function, working cage is rotat-
ed to the left.
1.
Push button
„Cage Rotation right“
 Push function, working cage is rotat-
ed to the right.
1.
Push button
„Cage down“
 Push function, working cage down-
wards (inclination).
1.
Push button
„Cage up“
 Push function, working cage upwards
(inclination).
1.
Push button
„Memorize position“
 Push function, save a target position
of the working cage that has been
moved into.
1.
Push button
„Move into position“
 Push function, move into a target
position of the working cage that has
been saved.
1.
Push button
„Searchlight“
(Optional extra)
 Push-to-lock-function, switching the
searchlight on cage on or off.
1.
Warning lamp, red
„LML-cut-off“
 Permanent light:
- Movements increasing the load
moment are locked.
 Blinking light:
- Blinks when a movement of the
Steiger is carried out with the fine
adjustment control switched on.
- Blinks if a „partly Emergency Cut-
Off“ is existent.
