ryan 544853G - Cut-Off Clutch..............................................Figure 1

45
ITEM PART NO. DESCRIPTION QTY
ITEM PART NO. DESCRIPTION QTY
HEAVY DUTY
SOD CUTTER
1 64006-03 WASHER, 3/8 HELICAL LCK 4
2 64001-3 NUT, 1/2-20 HEX JAM 2
3 306539 SCRW,.38-16.875 HX G5 4
4 64164-28 KEY-#808 WOODRUFF 1
5 641989-16 BLT-HEX EOC 1/4 - 20 X 1 2
(APPLY LOCKTITE #290 OR EQUIVALENT TO
THREADS PRIOR TO ASSEMBLY)
6 316924 SCRW,.25-28.38 BS HS G8 2
7 322494 O-RING,2.05.103 BUNA-N 70 1
8 515200 WSHR,.47.97.03 YS FLAT 2
9 516262 PLUG 2
10 516333 DISC 1
11 516338 SPROCKET 1
12 516343 WASHER, SPECIAL 1
13 518528 SPRING-PRESSURE PLATE 1
14 519904 LINER 1
15 520229 BEARING-THRUST 1
16 520231 WASHER-THRUST 2
17 521316 BOLT-SPECIAL 1
18 521477 SHIM, .015 (.381mm) 5
19 521478 SHIM, .005 (.127mm) 6
20 521480 RING-SEAL 1
21 521485 NUT-ADJUSTING 1
22 521486 BUSHING-CAM 1
23 521487 STOP-CAM 1
24 521490 ROLLER-CAM 2
25 521491 WASHER-THRUST 2
26 521495 RETAINER 1
27 521497 CAM 1
28 521498 ECCENTRIC 1
(APPLY LOCKTITE #290 OR EQUIVALENT TO
THREADS PRIOR TO ASSEMBLY)
29 521499 ROD-CONNECTING 1
30 521500 TRUNNION 1
31 521501 SHAFT-CLUTCH 1
32 521508 FLYWHEEL 1
33 521509 PLATE-PRESSURE 1
34 521511 WASHER-BELLEVILLE 3
35 545358 TIE ROD, COMPLETE 1
36 548111 BEARING-BALL 2
37 548112 BEARING-BALL 1
38 548115 BEARING-NEEDLE 2
39 548209 SET SCREW, 5/16-24x5/16 2
40 85010N ZERK-1/4-28 STR S-TAP 3
41 548225 FITTING-LUBE, 1/4-28, 45 2
42 548350 RING-LOCK 1
43 64139-02 BLT-WLF 1/4-20X1/2 2
44 800433 PLUG, 3/8-18 NPT 1
CUT-OFF CLUTCH
FIGURE 1
