51
ITEM PART NO. DESCRIPTION QTY
ITEM PART NO. DESCRIPTION QTY
HEAVY DUTY
SOD CUTTER
1 64006-03 WASHER, 3/8 HELICAL LCK 9
2 64025-24 NUT-HEX 7/16-20 3
3 64123-67 BLT-HEX 3/8-16 X 2 1
4 64006-06 LOCKWSHR-HELICAL 7/16 7
5 304364 NUT,.44-14 YS HEX 2
6 64025-04 NUT-3/8-24 HEX 1
7 64123-50 BOLT-HEX 3/8-16X1 7
8 64268-03 NUT-NYLN FLG LCK 3/8-16 1
9 64123-38 BLT-HEX 7/16-14X1 3
10 64018-39 BLT-CRG 3/8-16 X 1 3/4 1
11 64140-1 COTTER PIN-1/8X1 2
12 64163-61 WSHR .81X.406X16GA 2
13 64163-67 WASHER-.516X1X12GA 2
14 4163959.2 COVER-FRONT 1
15 316920 SCRW,.44-20 1.75 YS HX G5 3
16 64163-43 WSHR.443/.454X1X11GA 1
17 64188-64 PIN,CLEVIS3/8X 1.75 1
18 518476 SPRING,EXTENSION 1
19 4166807 S-GUARD, BELT REAR 1
20 4166670.7 LINK-CONTROL 1
21 4166667 SPACER BLK 1
22 520729.2 BRACE-FRONT 1
23 4163592 LABEL-WARN HANDS/BELT 2
24 521679 BUSHING 1
25 524589 PULLEY,3.90 DIA. BLK 1
26 4166488.7 LINK-CONTROL 1
27 4166464 BELT-DRIVE 1
28 4166504.2 MOUNT-ENGINE 1
29 524577 BUSHING 2
30 4151739 S-GUARD, BELT FRONT 1
31 4163976 LABEL-RYAN X-LARGE 1
32 4124293 LABEL-SIDE, HD SOD CTR 1
33 64141-4 NUT-WLF 3/8-16 1
34 64152-56 SCREW-HS S-TAP #12X1/2 3
35 35027N FITTING-lube. 1/4-28 90 DEG. 1
36 6416331 WSHR,.25/64 X1 X12 3
37 4166360.7 PLATE AY, PIVOT BLK 1
38 4166395.7 ARM AY BLK 1
39 4166588.7 ARM-IDLER 1
40 64163-61 WSHR .81X.406X16GA 8
41 64163-43 WSHR.443/.454X1X11GA 2
42 64163-46 WSHR,.383/.393X.88X7GA 1
43 64044-18 SSCRW-5/16-18X5-16 2
44 64164-10 KEY,.25X.25X1-1/4 SQUARE 1
45 64139-06 BLT-WLH 5/16-18X5/8 2
46 548902 SCRW,.31-18 1.00 HSF G5 2
47 64141-6 NUT, 5/16-18 2
48 548942 PULLEY, IDLER 3.25 DIA. 1
49 64123-289 BLT-HEX 3/8-16X5 1/2 1
50 524366 LABEL-BLADE ADJUST 1
51 524540 LABEL-INFORMATION 1
52 4116761 LABLE-MADE IN USA 1
53 340830 DECAL-CAUTION, SPANISH 1
54 64123-16 BLT-HEX 3/8-16X1-1/4 1
55 4166075 ENGINE-HONDA GX390 1
56 64262-014 BLT-FLG HD 3/8-16X2 4
57 64268-03 NUT-FLG NYLCK 3/8-16 5
58 4166856.7 ASY-DECLUTCH, HD 1
59 64123-54 BLT-HEX 5/16-18 X 3/4 2
60 64163-55 WSHR-.3628X.75X14GA 2
61 64006-02 LCKWSHR- 5/16 HELICAL 2
62 4166361.7 SPACER-ENGINE 1
63 64163-31 WSHR 25/64X1X12 1
* NOT ILLUSTRATED
ENGINE, MOUNT, & COVERS
FIGURE 4
