ryan 544853G - Blade, Mounts, Rocker Arms & Ram

55
ITEM PART NO. DESCRIPTION QTY
ITEM PART NO. DESCRIPTION QTY
HEAVY DUTY
SOD CUTTER
1 64141-4 NUT-WLF 3/8-16 1
2 64006-03 WASHER, 3/8 HELICAL LCK 3
3 64123-67 BLT-HEX 3/8-16X2 1
4 64123-173 BLT-HEX 3/8-16X4-1/2 1
5 4164000.2 GUARD-INNER 2
6 64229-03 NUT-NYLON LOCK 3/8-16 6
7 64123-100 BOLT-3/8-16X2-1/4 HEX 2
8 64025-02 NUT-HEX 5/16-18 2
9 * 320107 TIE, STRAP 2
10 64123-16 BLT-HEX 3/8-16 X 1-1/4 6
11 4137371 LABEL-CRUSH HAND 1
12 515537.7 MOUNT, BLADE 16" 1
(USED ON MODEL 544853G)
13 515538.7 MOUNT, BLADE 18" 1
(USED ON MODEL 544854G)
14 64164-05 KEY, WOODRUFF #404 1
15 800416 SCRW,.25-20 1.00 YS FR G5 6
16 64141-2 NUT-WLF 1/4-20 6
17 515547 BLADE, CUT-OFF, 16" SER 1
(USED ON MODEL 544853G)
18 515548 BLADE, CUT-OFF, 18" SER 1
(USED ON MODEL 544854G)
19 520420 SPRING-WALKING RAM 1
20 520426 SHAFT 1
21 520665 PLATE 1
22 521331 SHIM 4
23 521474 STOP, RAM 1
24 521475 WEAR BLOCK 2
25 521479 BUSHING 1
26 521488 REAR RAM ROLLER 1
(ITEM 26 TO BE USED WITH THE WALKING
RAM CUT-OFF ONLY. WHEN CONVERTING TO
ROLLING RAM FOLLOW THE INSTRUCTIONS
PROVIDED WITH THE ROLLING RAM
ACCESSORY PART # 545395.)
27 521489 SHAFT, ROCKER ARM 2
28 4151740 COVER-CUT-OFF W/ 1
29 521515 THRUST WASHER 4
30 521817 ARM-ROCKER 2
31 545390 RAM, CUT-OFF 1
32 548073 NUT,.62-18 YS FLEXLOCK 4
33 548080 BEARING, NEEDLE 2
34 548191 GROMMET 2
35 548223 SSCRW,.31-18 1.50 BS 2
36 548224 FITTING,GREASE 1/4-28 2
37 64152-56 SCRW-HS S-TAP #12 X 1/2 5
* NOT ILLUSTRATED
BLADE, MOUNTS, ROCKER ARMS & RAM
FIGURE 6
