ryan 544853G - Accessories-Sulky Roller

65
ITEM PART NO. DESCRIPTION QTY
ITEM PART NO. DESCRIPTION QTY
HEAVY DUTY
SOD CUTTER
1 64006-05 LOCKWSHR-HELICAL 1/2 1
2 64006-03 WASHER, 3/8 HELICAL LCK 12
3 64123-67 BLT-HEX 3/8-16X2 2
4 64140-1 COTTER PIN, 1/8 X 1.0 12
5 64123-50 BOLT-HEX 3/8-16X1 6
6 64025-05 NUT-3/8-16 HEX 12
7 64025-19 NUT-1/2-13 HEX 7
8 311398 SCREW, 1/2-13X3-1/2 1
9 515586 COLLAR 1
10 517052 SEAT 1
11 517951 PIN-PIVOT, 1/2x9-19/32 1
12 517968 PIN-CLEVIS, 1/2x4 2
13 517994 PIN-PIVOT, 1/2x5-5/8 2
14 518159 AXLE 2
15 518285 BAR-DRAG 1
16 518535 SPRING 3
17 800237 BOLT-CRG, 3/8-16x1-1/2 2
18 * 545434 SPACER-LEFT COMPLETE 1
(INCLUDES ITEM 19)
19 * 318243 PIN-ROLL, 3/8"x1" 1
20 545570 SPACER-RIGHT, COMPLETE 1
(INCLUDES ITEM 21)
21 318243 PIN-ROLL, 3/8"x1" 1
22 545609 FOOTREST 1
23 546321 SCREW, ADJUSTING 2
24 546998 BRKT-ADJUSTING 2
25 547002 SUPPORT-FRONT 1
26 547003 PIN-HITCH 1
27 547004 FRAME-SEAT 1
28 547005 PLATE-PIVOT 1
29 547006 SUPPORT-MIDDLE 1
30 547007 SUPPORT-REAR 1
31 547008 RACK-REAR 1
32 547011 BRKT-EXTENSION 1
(INCLUDES ITEM 33)
33 316949 PIN-SPIROL 1/4x1-1/8 5
34 547014 YOKE-EXTENSION 1
35 547016 YOKE-WHEEL 2
36 547018 WHEEL-COMPLETE 2
(INCLUDES ITEMS 37-41)
37 516491 CAP-END 2
38 548151 BEARING-ROLLER 2
39 85010N ZERK-, 1/4-28 STR S-TAP 1
40 548493 TIRE-4.8/4.00x8, 2 PLY 1
41 548880 STEM-VALVE 1
42 547042 CLAMP 1
43 547346 RACK-PRIMARY 1
(INCLUDES ITEM 44)
44 316949 PIN-SPIROL 1/4x1-1/8 32
45 547451 GUARD 1
46 64044-18 SETSCREW, 5/16-18 X 5/16 1
47 64163-31 WSHR-25/64X1X12 GA 2
48 545505 SULKY ROLLER, COMP. 1
(INCLUDES ITEMS 1-47)
* NOT ILLUSTRATED
ACCESSORIES-SULKY ROLLER (545505)
FIGURE 11
