ryan 544853G - Handlebars.....................................................Figure 8

59
ITEM PART NO. DESCRIPTION QTY
ITEM PART NO. DESCRIPTION QTY
HEAVY DUTY
SOD CUTTER
1 4166783 WIRE ASSY 1
2 4163774-02 TUBING-CORRUGATED 5FT 1
3 64006-03 WASHER, 3/8 HELICAL LCK 2
4 64123-89 BOLT-HEX 1/4-20X3/4 9
5 64025-04 NUT-3/8-24 HEX 2
6 516544 BUSHING-PLATED 2
7 64197-015 BLT-TDFM 10-32X1/2 TORX 2
8 48228A CABLE CLIP-INSULATED 1
9 64025-15 NUT, 10-24 KEPS HEX 1
10 64123-16 BLT-HEX 3/8-16X1-1/4 2
11 64163-03 WSHR-.256IDx62ODx18GA. 5
12 64229-05 NUT-NYLON LOCK 1/2-13 1
13 64123-24 SCREW, 1/2-13x1-3/4" 1
14 522585 HANDLE, CONTROL 2
15 522727 GRIP, HANDLE 2
16 4161125 LABEL-RYAN , OVAL,SMALL 1
17 4164043 LABEL-CONTROL PANEL 1
18 64163-86 WSHR-.265X.625X.125 4
19 4164025 S-CONTROL PANEL HD 1
20 4163620.7 BRKT-HANDLE MTG 2
21 540232 CONTROL-KILL SWITCH 1
22 540255 CONTROL AY,THROTTLE 1
23 4164021.7 WLDMT-HANDLE HD SOD 1
24 548171 KNOB 2
25 64229-01 NUT-NYLON LOCK 1/4-20 9
26 64152-18 SCRW-8-32X3/8 S-TAP 2
27 64189-20 BLT-HEX SOC 1/4-20X5/8 4
28 800495 NUT,.25-20 SPD "U" W/NUT 2
29 64123-270 BLT-HEX 3/8-24-2-1/4 2
30 806800 SWITCH, STOP LIGHT 1
31 64163-61 WSHR .81X.406X16GA 2
32 805421 SPRING, EXTENSION 1
33 814585 BUSHING 1
34 524472 ARM, PIVOT (PLATING) 1
35 64006-01 LCKWSHR-1/4 HELICAL 3
36 111898 CLAMP, CABLE 1
37 64152-46 SCRW-SLT 10-24 X 1/2 1
38 64163-55 WSHR-.328X.75X14 GA 1
* NOT ILLUSTRATED
HANDLEBARS
FIGURE 8
