ryan 544853G - Gear Case.........................................................figure 2

47
ITEM PART NO. DESCRIPTION QTY
ITEM PART NO. DESCRIPTION QTY
HEAVY DUTY
SOD CUTTER
GEAR CASE
FIGURE 2
1 64123-80 BLT-HEX 1/4-20X1-1/4 1
2 64006-01 LOCKWASHER-1/4 HELICAL 6
3 307665 NUT,.75-16 YS HX JAM 2
4 64025-19 NUT-1/2-13 HEX 1
5 309799 LWSHR,.75 ZS SHKPRF EXT 2
6 515607 SHIFTER LEVER 1
7 515618 SHAFT 1
8 515638 SPROCKET 1
9 515639 GEAR 1
10 515640 SHAFT 2
11 812009 BRG,BALL.67 1.57.47 "OP" 2
12 516158 PIN (PLATED) 1
13 518453 SPRING 1
14 520598 GEARCASE 1
15 520600 GEAR,45T X 4.70 O.D. 2
16 520601 GEAR, 48T X 5.00 O.D. 1
17 520621 SPACER 5
18 520688 GASKET 1
19 520722 SPACER 2
20 520723 SHAFT 1
21 521222 COVER-GEARCASE 1
22 524539 DECAL,GEAR LUBE 1
23 545626 SPROCKET AY 1
24 546070 ECCENTRIC 1
25 546071 FORK AY, SHIFTER 1
26 547398 CHAIN AY,#50 RLR 1
(INCLUDES ITEM 27)
27 * 548481 LINK-CONNECTOR 1
28 800113 PLUG,.5-14NPT PS SQ HD 1
29 547423 DRIVE WHEEL 16" 2
30 547424 DRIVE WHEEL 18" 2
31 548080 BEARING-NEEDLE 2
32 548322 RING-LOCK 2
33 548325 RING-LOCK 4
34 548327 RING-LOCK 2
35 64164-10 1/4X1/4X1-1/4 MACH KEY 2
36 548482 PLUG-EXPANSION, 1-1/4 2
37 64151-1 LOCKNUT, 1/4-20 1
38 548726 SCREW, MACH 1/4-20x3/4 6
39 548931 PLUG-EXPANSION, 1-3/4 2
40 548952 RING-RETAINING, INT 2
41 548953 BEARING-BALL 2
42 548954 SEAL-OIL 2
43 548984 SCREW, 1/2-13x4 1
44 553046 KEY-WOODRUFF, #3 1
* NOT ILLUSTRATED
