53
ITEM PART NO. DESCRIPTION QTY
ITEM PART NO. DESCRIPTION QTY
HEAVY DUTY
SOD CUTTER
1 64006-02 LOCKWSHR-HELICAL 5/16 6
2 64123-107 BLT-HEX 5/16-18X7/8 4
3 64123-61 BLT-HEX 5/16-18X1-3/4 2
4 328018 SCRW,.44-14 1.12 YS HX G5 6
5 515011 SCRW,.31-24 1.00 ZS HX G8 6
6 515729 BUSHING 2
7 516067 BUSHING 2
8 4135868 COVER-HANDLE 3
9 521435.7 SHAFT, LOWER 1
10 64163-31 WSHR-25/64 X 1 X 12 1
11 2308066 WSHR-FRICTION .390X1.12 1
12 4114727 KNOB-SPEED CONTROL 1
13 521472 BRACKET-PIVOT 2
14 4164681 S-ECCENTRIC AY 2
(INCLUDES ITEMS 15 & 16)
15 521424 RING 1
16 548814 RACE-INNER, NEEDLE BRG 1
17 545437 ARM AY 2
(INCLUDES ITEMS 18-22)
18 64197-025 BLT-TDFM 1/4-20X5/8 4
19 521425.2 PLATE-COVER 2
20 521427 ARM, PITMAN 2
21 521428 BEARING, NEEDLE 2
22 85010-03 ZERK-1/8 NPT, STR 2
23 545443.2 BRACKET-PIVOT, COMPLT 2
(INCLUDES ITEMS 24 & 25)
24 521429 BRONZE BEARING 1
25 85010N ZERK-1/4-28 STR S-TAP 1
26 4153500 ARM-SIDE, COMPLETE 2
(INCLUDES ITEMS 27-31)
27 521436 BALL BEARING 2
28 521438 GREASE SEAL 2
29 548138 BEARING, NEEDLE 4
30 64164-42 LOCK RING 4
31 85010N ZERK 1/4-28 STR STHRD 4
32 4164541.2 LEVER-DEPTH CONTROL 1
33 4164517.2 H-FRAME 1
34 4164570.2 HANDLE 2
35 524549 ROD, TIE LOWER 1
36 524550 ROD, TIE UPPER 1
37 64163-98 WSHR- 1.25X.76X18GA 2
38 64268-03 NUT-FL NY LOCK 3/8-16 2
39 64151-7 LOCKNUT, 1/2-13 HEX 2
40 64123-50 BOLT-HEX 3/8-16X1 2
41 64163-99 WSHR-.510X1.31X.179 4
42 4164033 LABEL-CHF VERT 2
43 548056 NUT,.44-14 YS HX UNITORQ 6
44 64025-03 NUT-HEX 5/16-24 6
45 564006-16 LWSHR,.5/16 HI-COLLAR 2
46 64151-33 NUT-HEX 1/2-20 LOCK JAM 2
47 800513 SCREW-SH 5/16-18-1-1/4 2
48 64141-9 NUT-WLF 5/16-18 CL 4
49 4132716.7 WLDMT-SOD CUTTER, 16" 1
(USED ON MODEL 744853G)
50 4132717.7 WLDMT-SOD CUTTER, 18" 1
(USED ON MODEL 744854G)
51 4113281 WASHER-SPCL .531 2
52 64268-02 NUT-FL NY LOCK 5/16-18 2
53 64018-7 BLT-CRG 3/8-16 X 1 1/4 1
54 4164484 LABEL-CUT DEPTH 1
55 4164446 PLATE ADJUSTMENT STOP 1
56 64268-03 NUT-FL NYLOCK 3/8-16 1
CONTROL HANDLES, PITMAN & SIDE ARMS
FIGURE 5
