57
ITEM PART NO. DESCRIPTION QTY
ITEM PART NO. DESCRIPTION QTY
HEAVY DUTY
SOD CUTTER
1 64197-025 TSCRW,.25-20.62 YS HW 2
2 64163-86 WSHR-.265X.625X.125 1
3 64123-89 BOLT-HEX 1/4-20X3/4 12
4 301988 NUT, .5-20 YS HX 1
5 64141-6 NUT-WLF 5/16-18 1
6 64006-06 LOCKWSHR-HELICAL 7/16 2
7 64001-6 NUT-HEX JAM,3/8-16 1
8 306025 LWSHR,.38 YS SHKPRF 2
9 64025-04 NUT-3/8-24 HEX 2
10 64025-01 NUT-1/4-20 HEX 12
11 64006-01 LOCKWASHER-1/4 HELICAL 19
12 64025-23 NUT-HEX 1/4-28 1
13 64123-68 BOLT-HEX 5/16-18X1 1
14 306488 LWSHR,.25 ZS SHKPRF A/R
15 524577 BUSHING, RUBBER 2
16 64123-15 BOLT-3/8-16X3/4 HEX 4
17 64123-16 BLT-HEX 3/8-16X1-1/4 3
18 64123-38 BLT-HEX 7/16-14X1 2
19 309067 LWSHR,.50 YS SHKPRF EXT 1
20 309978 O-RING 1
21 515494 DOG , TRIP A/R
22 515534 SEGMENT 6
23 515962 BRACKET-HANDLE MNT 1
24 516237 WASHER,.505.75.0149 FL 2
25 516259 PLATE-SPACER A/R
26 516384 SPROCKET, 12 TOOTH 1
27 516387 SPROCKET, 9 TOOTH 1
28 518225 COVER 1
29 518240 GUARD 1
30 4164017.7 ADJUSTER 1
31 518275 SHAFT 1
(APPLY LOCKTITE #290 OR EQUIVALENT TO
THREADS PRIOR TO ASSEMBLY)
32 518277 SPACER (PLATED) 1
33 518499 SPRING 1
34 518504 SPRING 1
35 520028 WASHER, .50.75.06 YS FLAT 1
36 520374 WSHR,1.031 2.00.06 YS FLT 1
37 520673 BRACE-REAR 1
38 521494 DUST COVER 1
39 521496 BUSHING, DOG WHEEL 1
40 4157141 TRIGGER 1
41 521516 COVER, INSPECTION HOLE 1
42 4164016.7 BAR,LINK, LIFT, LONG 1
43 524003 SPACER, CUT-OFF A/R
44 545357 HOUSING-DOG WHEEL 1
(INCLUDES ITEM 45)
45 518252 BUSHING 2
46 4157143 TRIP ARM AY 1
47 545389 SHAFT AY 1
48 545397 CASE, CUT-OFF, COMPLT 1
(INCLUDES ITEM 49)
49 516261 BUSHING 2
50 545403 WHEEL-DOG 1
51 546064 WHEEL-METERING 1
52 546247 SPROCKET AY 1
53 547026 CHAIN, #35, 100 LINKS 1
(INCLUDES ITEM 54)
54 * 548760
LINK, #35 CONNECTOR 1
55 547240 CHAIN, #35, 30 LINKS 1
(INCLUDES ITEM 56)
56 * 548760
LINK, #35 CONNECTOR 1
57 64140-1 COTTER PIN-1/8 X 1 1
58 548115 BEARING 4
59 64163-55 WSHR-.328 X .75 X 14GA 1
60 85010N ZERK-1/4-28 STR S-TAP 3
61 548319 BEARING, ROLLER 1
62 548726 SCRW,.25-20.75 YS RS 6
63 548756 SCRW,.25-20.50 YS PS G5 A/R
64 64141-4 NUT-WLF 3/8-16 4
65 548898 SCRW,.25-20 1.00 HSF G5 1
66 64188-63 PIN-CLEVIS, 5/16 X 1.75 1
67 64123-87 BOLT-HEX 3/8-16X1-3/4 1
68 64164-05 KEY, WOODRUFF #404 1
69 64229-01 NUT-NYLOC 1/4-20 2
70 64189-20 BLT-HEX SOC 1/4-20X5/8 2
71 64163-31 WSHR 25/64X1X12 2
* NOT ILLUSTRATED
CUT-OFF CASE, METERING WHEEL
FIGURE 7
