61
ITEM PART NO. DESCRIPTION QTY
ITEM PART NO. DESCRIPTION QTY
HEAVY DUTY
SOD CUTTER
1 64006-06 LOCKWSHR-HELICAL 7/16 2
2 304364 NUT-HEX 7/16-14 2
3 64001-6 NUT-HEX JAM, 3/8-16 2
4 64006-03 LOCKWASHER, 3/8 2
5 64123-75 BOLT, 3/8-16X3 HEX 2
6 311397 SCRW,.44-14 3.00 YS HX G5 2
7 316942 PIN,SPIROL.250.500 PS 2
8 515759 BUSHING 2
9 515888 WASHER,.62.88.15 NS FLAT 2
10 515958 PLUNGER 2
11 520605 WASHER-THRUST 2
12 520606 PIVOT-CENTER 1
13 520617 STRIP-BUSHING 1
14 823269 WASHER, 7/16 2
15 524809.7 SCRAPER-WHEEL 2
16 64163-67 WASHER-.516X1X12GA 2
17 546153 BARREL-WHEEL 2
18 547403 ARM-WHEEL 2
19 547404 AXLE 1
20 4124197 WHEEL-REAR 2
*523261 TUBE 1
*523262 TIRE 1
*523263 BEARING 1
21 547414 YOKE, COMPLETE 2
(INCLUDES ITEM 22)
22 516915 BUSHING 2
23 64151-7 NUT-HEX 1/2-13 CTRLCK 2
24 64229-03 NUT-NYLON LOCK 3/8-16 2
25 548206 SET SCREW, 3/8-16x1-1/2 2
26 85010N ZERK-1/4-28 STR S-TAP 1
27 64123-135 BLT-HEX 1/2-13X5 2
28 523053 SPACER,.51 .75 3.28 ZS 2
29 35027N FITTING-ZERK 90DEG. 2
30 816449 WASHER 2
* NOT ILLUSTRATED
REAR WHEELS
FIGURE 9
