Installation
18
Yellow -
Constant 12V+ source.
Red -
Ignition
controlled
ACC 12V+ source.
Black -
Ground (-) Polarity (Connect
to car chassis or ground point)
Green - Reverse Trigger (+) (Connect to reverse wire)
Step 3
Turn the vehicle on and verify that all the functions are working properly.
NOTE
separately). Please contact Rydeen Tech Support (Toll-Free 1-877-777-
8811) for more details.
The 6 PIN connector is for BSD blind spot monitoring systems (sold
