See Figures 2-3, 37, 42-45.
1. Stop the engine before setting the chain tension.
2. Slightly loosen the clutch cover lock knob by pressing
in and rotating counterclockwise. (Figure 37)
3. Turn the chain tensioning dial clockwise to tension the
chain. (Figure 44)
Figure 3)
1. Lift the tip of the guide bar up to check for sag. (Figure
43)
2. Release the tip of the guide bar and turn the chain
tensioning dial clockwise. Repeat this process until
sag does not exist.
3. Hold the tip of the guide bar up and tighten the clutch
cover lock knob securely. The chain is correctly
tensioned when there is no sag on the underside of
the guide bar, the chain is snug, but it can be turned
by hand without binding. Ensure that the chain brake
is not set.
