Ryobi RCS4240B Type III User Manual

10
English (Original Instructions)
SPECIFICATIONS
Model name
RCS4235B Type III RCS4240B Type III
Description
42cc 35cm (14'') CE saw 42cc 40cm (16'') CE saw
Weight - No bar, chain, fuel
4.7 kg 4.7 kg
Fuel tank capacity
340 cm
3
340 cm
3
Lubricant tank capacity
192 cm
3
192 cm
3
Maximum chain speed at the
recommended maximum engine speed
23.8 m/s 23.8 m/s
Bar length
35 cm 40 cm
Usable cutting length
33.3 cm 37.0 cm
Chain pitch
9.53 mm (0.375 inch) 9.53 mm (0.375 inch)
Chain gauge
1.27 mm (0.05 inch) 1.27 mm (0.05 inch)
Chain type
3/8” low prole full complement 3/8” low prole full complement
Drive sprocket
6 teeth x 3/8'' 6 teeth x 3/8''
Engine displacement
42 cm
3
42 cm
3
Maximum engine power (ISO 7293)
1.7 kW 1.7 kW
Recommended maximum
engine speed with cutting attachment
12,500 min
-1
12,500 min
-1
Engine idling speed range
2,600-3,600 min
-1
2,600-3,600 min
-1
Specic fuel consumption at maximum
engine power
426 g/kw.h 426 g/kw.h
Sound pressure level (ISO 22868)
LpAav: 101 dB(A), KpA=3 dB(A) LpAav: 101 dB(A), KpA=3 dB(A)
Sound power level (ISO 22868)
114 dB(A) 114 dB(A)
Vibration (ISO 22867):
- Front Handle
- Rear Handle
Carlton/Oregon
8.2 m/s
2
, K=1.5
7.7 m/s
2
, K=1.5
Carlton/Oregon
8.2 m/s
2
, K=1.5
7.7 m/s
2
, K=1.5
