Page 19
Fig. 23
LONG WORKPIECE
WORKPIECE SUPPORTS
SUPPORT LONG WORKPIECES
See Figure 23.
Long workpieces need extra supports. Supports should be
placed along the workpiece so it does not sag. The support
should let the workpiece lay flat on the base of the saw and
work table during the cutting operation. Use the work clamp
or a C-clamp to secure the workpiece.
OPERATION
WARNING:
To avoid serious personal injury, always keep your hands
outside the no hands zone and at least 3 in. (76.2 mm)
from blade. Never perform any cutting operation free-
hand (without securing workpiece against the fence). The
blade could grab the workpiece if it slips or twists.
45
15
0
30
15
30˚
