Ryobi TS1300 - Page 25

Page 25
The model number will be found on a plate attached to the motor housing. Always mention the model number in all correspondence regarding your
MITER SAW or when ordering repair parts.
1 800130-502 Screw ......................................................................4
2 588002-005 Motor Housing ........................................................1
3 981315-001 Set Screw (M5 x 6) .................................................2
4 981313-001 Nylon Set Screw (M5 x 6) .......................................2
5 982006-001 Data Plate ...............................................................1
6 976684-001 Brush Holder ...........................................................2
7 900030-402 Screw (M4 x 25)......................................................3
8 976683-001 Brush Assembly ......................................................2
9 976682-001 Brush Cap ...............................................................2
10 982024-001 Warning Label.........................................................1
11 588016-004 Handle Cover ..........................................................1
12 588014-002 Compression Spring ...............................................1
13 595008-004 Lock-Off Lever ........................................................1
14 976678-001 Switch Spring ..........................................................1
15 595025-006 Switch Holder..........................................................1
16 595004-000 Switch Trigger .........................................................1
17 976795-001 Field ........................................................................1
18 595007-008 Switch .....................................................................1
19 900030-401 Screw (M4 x 12)......................................................2
20 976673-001 Cord Clamp.............................................................1
21 976671-001 Connect Wire ..........................................................1
22 977439-001 Power Cord .............................................................1
23 976688-001 Bend Relief .............................................................1
24 901010-506 Screw (M5 x 60)......................................................2
25 588017-000 Fan Casing .............................................................1
26 976873-001 Ball Bearing ............................................................1
27 976794-001 Armature Assembly (Inc. Key Nos. 26, 34 & 35)....1
28 588025-003 Handle Washer .......................................................2
29 170030-601 Screw ......................................................................2
30 300030-100 Hex Nut (M10) ........................................................1
31 180031-002 Depth Stop Adjustment Screw (M10 x 20) .............1
32 300030-121 Hex Nut (M12) ........................................................2
33 350312-260 Flat Washer (M12) ..................................................1
34 976874-001 External Retaining Ring ..........................................2
35 976875-001 Ball Bearing ............................................................1
36 586004-108 Frame Arm ..............................................................1
37 588024-007 Carrying Handle ......................................................1
38 976650-001 Spindle Lock Pin .....................................................1
39 976651-001 E-Ring .....................................................................1
40 976649-001 Compression Spring ...............................................1
Key Part
No. Number Description Quan.
FIGURE A PARTS LIST
Key Part
No. Number Description Quan.
RYOBI 10 in. (254 mm) MITER SAW – MODEL NUMBER TS1300
41 452040-401 Square Key (4 x 4 x 28) ..........................................1
42 588030-008 Gear Shaft ..............................................................1
43 098460-040 Ball Bearing (6004ZZ) ............................................1
44 588031-004 Screw (Special).......................................................2
45 588023-001 Lock Pin Cap ..........................................................1
46 630000-000 "O" Ring ..................................................................1
47 588022-102 Lock Pin ..................................................................1
48 470000-600 E-Ring .....................................................................1
49 800030-401 Screw (M4 x 16)......................................................1
50 588021-009 Rubber Bumper ......................................................1
51 989377-002 Ball Bearing (6000LLB) ..........................................1
52 588028-001 Gear ........................................................................1
53 588029-007 Lock Ring ................................................................1
54 130030-501 Screw (M5 x 10)......................................................1
55 976739-001 Lower Blade Guard Bracket ................................... 1
56 350105-131 Washer (M5) ...........................................................1
57 589015-001 Screw ......................................................................1
58 350304-100 Washer M4) ............................................................1
59 130030-601 Bolt (M4 x 10) .........................................................1
60 588041-009 Connect Plate .........................................................1
61 350308-200 Flat Washer (M8) ....................................................1
62 588042-005 Link Nut ...................................................................1
63 981641-001 Lower Blade Guard .................................................1
64 976554-001 Return Spring..........................................................1
65 976548-001 Blade Bolt (M8 x 20) ...............................................1
66 976547-001 Blade Washer .........................................................2
67 982023-001 Blade .......................................................................1
68 588075-008 Label-Upper Guard .................................................1
69 100030-501 Screw (M5 x 12)......................................................5
70 190010-401 Phillips Screw .........................................................1
71 588048-001 Lock Nut..................................................................1
72 130030-401 Screw (M4 x 15)......................................................1
73 589031-007 Stopper ...................................................................1
74 317030-050 Lock Nut..................................................................1
75 350305-122 Washer (M5) ...........................................................1
76 589034-005 Deflector .................................................................1
77 317030-040 Lock Nut..................................................................1
78 976731-001 Upper Blade Guard Assembly ................................1
79 976757-001 Dust Guide ..............................................................1
80 588068-001 Logo Plate...............................................................1
