The model number will be found on a plate attached to the motor housing. Always mention the model number in all correspondence regarding your
MITER SAW or when ordering repair parts.
FIGURE B PARTS LIST
RYOBI 10 in. (254 mm) MITER SAW – MODEL NUMBER TS1300
1 360308-142 Lock Washer (M8) .............................................................................................................................................................4
2 710308-045 Bolt (M8 x 45) ....................................................................................................................................................................4
3 981313-001 Nylon Set Screw (M5 x 6).................................................................................................................................................. 2
4 982013-001 Fence .................................................................................................................................................................................1
5 588049-007 Spring ................................................................................................................................................................................1
6 982011-001 Mounting Bracket...............................................................................................................................................................1
7 360310-182 Lock Washer......................................................................................................................................................................3
8 588058-006 Screw .................................................................................................................................................................................1
9 700310-025 Screw (M10 x 25 Hex Socket) ...........................................................................................................................................2
10 982010-001 Miter Table .........................................................................................................................................................................1
11 588056-004 Shim...................................................................................................................................................................................4
12 982009-001 Miter Lock Plate .................................................................................................................................................................1
13 588061-009 Fixed Plate .........................................................................................................................................................................1
14 588060-003 Indexing Plate ....................................................................................................................................................................1
15 140030-500 Screw (Pan Head) .............................................................................................................................................................1
16 982008-001 Miter Lock Handle..............................................................................................................................................................1
17 589015-007 Control Arm .......................................................................................................................................................................1
18 360306-121 Lock Washer......................................................................................................................................................................4
19 700306-020 Bolt.....................................................................................................................................................................................4
20 982007-001 Miter Table Base ............................................................................................................................................................... 1
21 976569-001 8 mm Hex Key ...................................................................................................................................................................1
22 976605-001 6 mm Hex Key ...................................................................................................................................................................1
23 791050-000 5 mm Hex Key ...................................................................................................................................................................1
24 4240024 Blade Wrench ....................................................................................................................................................................1
4090001 Optional Dust Bag (Not Shown) ........................................................................................................................................1
982021-001 Optional Work Clamp (Not Shown) ................................................................................................................................... 1
982022-001 Optional Table Extensions with Stop Block (Not Shown) .................................................................................................1
972000-746 Operator’s Manual
Key Part
No Number Description Quan.
