29 − English
CUTTING WARPED MATERIAL
See Figures 39 - 40.
When cutting warped material, always make sure it is
positioned on the miter table with the convex side against
the fence as shown in figure 39.
If the warped material is positioned the wrong way as shown
in figure 40, it will pinch the blade near the completion of
the cut.
WARNING:
To avoid a kickback and to avoid serious personal injury,
never position the concave edge of bowed or warped
material against the fence.
CLAMPING WIDE WORKPIECES
See Figure 41.
When cutting wide workpieces, such as 2 in. x 6 in., boards
should be clamped with a work clamp as shown in figure 41.
Fig. 40
Fig. 41
WRONG
OPERATION
WIDE
BOARD
