28 − English
OPERATION
Fig. 39
RIGHT
VERTICALLY CUTTING BASE MOLDING
AGAINST THE MITER FENCE
See Figure 38.
Set the bevel angle at 0° and the miter angle at 45° to
either the left or the right. (For making 90° corners.)
Place and secure the base molding vertically against the
fence using a spring clamp and hold the base molding
securely.
NOTE: To avoid interference between the base molding
and the motor, the molding should be placed no more than
a half-inch over the throat plate when cutting or trimming
base molding at 45° right miter angles.
Before turning on the saw, perform a dry run of the cut-
ting operation to make sure that no problems will occur
when the cut is made.
Grasp the saw handle firmly. Squeeze the switch trigger.
Allow several seconds for the blade to reach maximum
speed.
Slowly lower the blade into and through the base molding.
Fig. 38
