16 − English
45
30
15
0
SIDE HANDLES
See Figures 12 - 13.
Side handles have been provided for both the left and the
right side of the saw.
To install side handles:
 Align the holes in one of the side handles with the holes
in the saw base.
 Insert the provided hex screws into the holes and tighten
securely using the blade wrench provided.
 Repeat for other side handle.
Fig. 13
Fig. 12
HEX SCREW
SIDE
HANDLE
SIDE
HANDLE
BASE
BASE
ASSEMBLY
HEX SCREW
