Sabre 15538 Hydro - ELECTRICAL SCHEMATIC

ELECTRICAL SCHEMATIC ELECTRICAL
3/5/97 4 - 5
ELECTRICAL SCHEMATIC
201 RED
401 YEL
RED
710 PUR
100 BLK
105 BLK
STATOR
STARTER MOTOR
START
SOLENOID
IGNITION
FUEL
SOLENOID
SHUT-OFF
(16 HP ONLY)
2 1
0 = OFF 1 = RUN
0
2 = START
0,1
FRAME GROUND
G
BATTERY
220 RED/BLK
ENGINE
CONNECTOR
15A
M
451 YEL/WHT
940 WHT
120 BLK
110 BLK
945 WHT/BLK
941 WHT
700 PUR
BLADE
IGNITION MODULE
SPARK PLUG
DRIVE
SEAT
COIL
10
0 = OFF SEAT 1 = ON SEAT
1
0
0 = OFF 1 = ON
0 = OFF 1 = ON
0
1
BRAKE
HEADLIGHTS
ENGINE
CONNECTOR
SWITCH
SWITCH
705 PUR/WHT
HEADLAMP CONNECTOR HARNESS
200 RED
202
201 RED
RED/WHT
946 WHT/BLK
946A
WHT/BLK
941A WHT
942 WHT
710 PUR
FUSE
SWITCH
DIODE
SWITCH
