Operating instructions
5.3.4 Valve positions during operation, LP ChillPAC (external condenser)
Pos. no.
Designation In-operation position
400
Compressor unit valves
Please see the compressor manual
401 Compressor suction stop valve Open
402
Compressor discharge stop valve Open
A Motor stop valve - condenser
Open
B Motor stop valve - condenser
Open
45
Stop service valve for oil recovery/oil return Open
423
Stop valve (2 pcs.) - expansion Open
427
Stop valve for pressure gauge Open
428
Oil/R717 drain stop valve Closed
429 Purge valve
Closed
431 Stop valve for oil drainage Open
432 Charge valve (R717) Closed
433
Stop valve for oil recovery Open
434
Stop valve for oil recovery Open
436
Stop valve for oil recovery Open
437 Stop valve for oil return Open
438 Drain valve (quick closing) Closed
442 Double stop valve
One outlet open / one outlet closed
443
Safety relief valve (Closed) Fixed set point
444
Safety relief valve (Closed) Fixed set point
445 Double stop valve
One outlet open / one outlet closed
446
Safety relief valve (Closed) Fixed set point
447
Safety relief valve (Closed) Fixed set point
Table 2: Valve positions during operation, LP ChillPAC
