39
1
2
4
3
CAUTION
The battery may only be connected or
disconnected while the ignition is inac-
tive.
First disconnect the minus terminal (3,
black cable).
When in stall ing the bat tery, fi rst connect
the plus terminal (4, red cable).
The battery is main te nance-free. Do not
try to open it.
NOTES ON MAINTENANCE
Removing and installing the battery
- Turn off the ignition.
- Remove the two screws (1).
- Open the inspection cover (2).
- Disconnect the battery.
- Remove the battery.
Installation takes place in reverse order to
disassembly.
