MAIN PARTS
2
1
3
4
5
7
8
9
10
11
12
12
13
Fig. 1
1 Display
2 Keypad
3 Coin slot
4 Coin value label
5 Coin return button
6 Showcase
7 Coin return slot
8 Product dispensing tray
9 Air suction grill
10 Handle with lock
11 Power cord outlet
12 Fuse
13 Compressor
6
31
14 Double motor
15 Single motor
16 R.-H. spiral (snack dispensing tray)
17 L.-H. spiral (snack dispensing tray)
18 Snack guide on double spiral
19 Label strip
20 Spacer
21 Spiral
22 Bridge support for bottles or cans
23 Safety microswitch
24 Adjustable stop bar
25 Tray connector
26 Neon light
27 CPU card
28 Coin guide
29 Coin support plate
30 Coin container
31 Operating instruction label
