6 DESCRIPTION OF CONTROLS
6.1 Display
The display shows the messages during standard
operation, programming and maintenance modes.
6.2 Keypad
Each key function changes
according to the vending
machine mode (ordinary
dispensing or programming
mode).
Each key has a double
function that varies
according to the vending
machine status (standard
operation or programming).
6.3 Key description in standard
operation mode
6.3.1 Set 1 Pre-selection button
The function connected to the button may be chosen from
the following options:
A. Beverage 5
B. Pre-selection of beverages 9-16
C. Disabled
6.3.2 Keys (1 to 8)
By pressing these keys, the programmed beverages are
dispensed.
6.4 CPU card keys
The CPU electronic card has 4 keys enabling the
Maintenance Technician to carry out programming or
maintenance operations.
P1
Programming menu key
P2
Maintenance menu key
P3
Machine Ready / Free Button
P4
Reset key
