USER MANUAL - SIP POWER ION PUMP CONTROLLER
M.HIST.0109.23 Rev.1 Page 33 of 62
 Bit 15:8 – Software version major number
This is the software version major number.
 Bit 7:0 – Software version minor number
This is the software version minor number.
SERIAL_NUMBER – 0x1003 – Serial number
Bit 31 30 29 28 27 26 25 24
SERIAL NUMBER[31:24]
R/W R R R R R R R R
Bit 23 22 21 20 19 18 17 16
SERIAL NUMBER[23:16]
R/W R R R R R R R R
Bit 15 14 13 12 11 10 9 8
SERIAL NUMBER[15:8]
R/W R R R R R R R R
Bit 7 6 5 4 3 2 1 0
SERIAL NUMBER[7:0]
R/W R R R R R R R R
 Bit 3:0 – Serial number
These registers show the device serial number.
Status Registers
These registers are useful to retrieve information about the power supply status.
LIFE_TIME – 0x2000 – Total working hours
Bit 31 30 29 28 27 26 25 24
LIFE_TIME[31:24]
R/W R R R R R R R R
Bit 23 22 21 20 19 18 17 16
LIFE_TIME[23:16]
R/W R R R R R R R R
Bit 15 14 13 12 11 10 9 8
LIFE TIME[15:8]
R/W R R R R R R R R
Bit 7 6 5 4 3 2 1 0
LIFE TIME[7:0]
R/W R R R R R R R R
