USER MANUAL - SIP POWER ION PUMP CONTROLLER
M.HIST.0109.23 Rev.1 Page 34 of 62
Bit 31:0 – Total working hours
These registers show the device total working hours (only the time spent supplying current).
TEMPERATURE – 0x3000 – Internal temperature
Bit 15 14 13 12 11 10 9 8
TEMPERATURE[15:8]
R/W R R R R R R R R
Bit 7 6 5 4 3 2 1 0
TEMPERATURE[7:0]
R/W R R R R R R R R
Bit 15:0 – Internal temperature
These registers contain the device internal temperature reading provided in Kelvin degrees.
ARCING_NUMBER – 0x3001 – Arcing events number
Bit 15 14 13 12 11 10 9 8
ARCING NUMBER[15:8]
R/W R R R R R R R R
Bit 7 6 5 4 3 2 1 0
ARCING NUMBER[7:0]
R/W R R R R R R R R
Bit 15:0 – Arcing events number
This register contains the number of arcing events since last start (or restart) command.
STATUS – 0x3002 – Power supply status
Bit 15 14 13 12 11 10 9 8
‒ ‒ ‒ ALM_COMM ALM_ARCING ALM_IOUT ALM_VOUT ALM_VIN
R/W R R R R R R R R
Bit 7 6 5 4 3 2 1 0
ALM_OVERTEMP ALM_INTERLOCK ALM_SAFE ALARM IOUT_GRADIENT NEED_RESTART ENABLE
R/W R R R R R R R R
Bit 15:13 – Reserved bits
These bits are reserved for future use.
Bit 12 – Communication alarm
This alarm latch is set when the device (Modbus Master or Ethernet Master) who started the power
supply (sent enable start or enable restart commands) does not send any request for KEEPALIVE
ms.
Bit 11 – Arcing alarm
This alarm latch is set when the power supply detects a arcing event.
Bit 10 – Output over-current alarm
This alarm latch is set when the power supply detects a output over-current event. This alarm latch
is set only if switch SW1 mode is set to ON and the output current increases over
